Multi touch screen video wall 3x3 of 46inch lcd video wall 3.5mm bezel

  • MODEL: FH-D3D460CT
  • Price: US $800.00
  • Quantity: Inquiry for the Wholesale price

1,Multi touch points touch screen make a large wall shinning;

2,The gaps between 2 units monitors is 3.5mm;

3,Up to 32points Multi-Touch with Multi-Users;

4,Ultra large touch wall size is customization;

5,Easy operation with free software to control video wall;

6,Support RS-232 serial ports remote control;

8,Panels splicing freely like 2X2, 3X3 etc.

  • Quantity:
  • Bookmark and Share
    • Product Details
    • Specifications
    • FAQ

    Multitouch Screen Video Wall

    One of the fastest growing technology, businesses are using is multi touch screen video walls. Video walls are used to display large amount of information for the viewers to promote the business activities. Felehoo multi touch screen video wall is ultra slim video wall that is appropriate for public places and events like conferences, seminars, business meetings etc.

    We, at Felehoo have ample of these video walls ranging from 46 inches to 500 inches with high quality high definition display that is suitable for any gatherings such as tournaments, family functions, business related collaborations etc.

    Our multi touch screen video wall comes with standard features such as multiple signal inputs, full high definition display, easy installation, split screen and many more. Our multi touch screen video wall allows multiple users to simultaneously interact with the video wall without disturbing other users.

    Our products can be used in schools, companies, hotels, cafes and restaurants etc. We provide high quality multi touch screen cheap video wall that can easily come in your budget.

    We, at Felehoo have expert team in designing touchscreen video wall for our clients. Our expert team members have large number of expertise in designing premier touch screen tables. We, at Felehoo are dedicated to provide fine quality products and services. Felehoo has become one of the most leading touchscreen video wall manufacturer. We are successful in winning trust of our customers.

    We customize our products depending on customers’ requirements. We can design multi touch screen video wall based on different specifications such as weight, design, dimensions and power consumption etc. We design cheap video walls for our customers that suits their budget.

    If you want multi touch screen video wall for your business, we are delighted to design it for you as per your desire. Contact us for free quote or free consultation

    The 46'' DID video wall screen series features on only 3.5mm edge to edge ultra narrow bezel with LCD technology making these the perfect solution for a tightly mounted side by side security surveillance video wall.The 46'' series is designed with no buttons or lights on the bezel, RS232 for computer control, 2 video BNC In/Out, and many other inputs.Ideal solution requiring multiple monitors to be installed on one wall or upgrading your CRT's to LED's.

    Felehoo is leading the market as being an expert in control room solutions for broadcasting, telecommunications, public utilities,process control, traffic control,surveillance and command&control applications. Felehoo LCD&LED video wall solutions are ideal for Emergency Operations Centers,traffic and surveillance centers and utilities and process control room.Unlike plasma technology, Felehoo LCD&LED video walls require less power consumption and with auto pixel shift built in they are not subject to permanent, irreversible burn-in, unlike LCD's that have gaps/space between each monitor, tiled video walls offer more flexibility, stability and the possibility for a higher resolution.

    Build a easy multi-touch screen video wall easily,easy connect to make a large touch wall with a hdmi splitter only.DIY a touch wall easily here,we could accept custom design service!

    Build a professional touch video wall need a matrix to connect all input device an output monitors.Best design for a cctv wall with cctv cameras.

    Felehoo LCD&LED Video Wall provide many kinds of solutions with variety of signals. Our LCD Video Wall is easy to install and maintain, with high stability and reliability,Providing cost-effective products and customer-oriented services.we are not just selling the complete set of equipment but also technical support service.

    In general, our offer only includes Original DID LCD or LED Screen Panel with video wall controller, free control software,

    Easy installation bracket and related Accessories(VGA Cables or RJ45 Cables, Power Cables).As for other devices, you need prepare them by yourself, Our quotation not include PC,VGA/HDMI Splitter, RS232-RJ45 Connectors and Connection matrix,

    Unless you need them from us here, we can also buy them for you from the market. Besides, If you have a large project, need some help from our company. We can also arrange our engineer to go to your country to provide the in-door installation and equipment debugging service if you would like to afford the related expenses of traveling.

    Main Functions:

    1,Integrating multiple signal decoding unit,a liquid crystal drive unit,power supply unit and other parts, can flexible and easily form a large screen display system.

    2,All hardware made, professional mosaic chip design, no CPU, operating system and virus infection risk, security and stability.

    3,Multi-bus parallel processing,speed and powerful.

    4,Integrated with multi-channel video sources : HDMI,DVI,VGA,CVBS,USB,NETWORK(rj45),HDMI,DVI,VGA,Y/Pb/Pr,CVBS,USB.

    5,Integrated with media codecs,support for H.264,MPEG-2,RMVB,MKV,VC-1 and other encoding formats, support up to 1080P resolution video for each monitor,4K 2x2, 6K 3x3 or 8K 4x4 array that works best in the application.

    6,Embedded 3D video high color separation circuit unit, 3D digital noise reduction processing unit and the progressive normalization frame rate conversion circuit unit.

    7,Support edge compensation, reflecting the overall effect.

    8,Can supply the underlying communication protocol,helping user to construct large-screen systems with the third-party or self-preparation software engineering flexibly.

    9,Embedded smart upgrade firmware system.

    10,Designed for high load and long time display applications,support running 24 hours a day continuously.

    So many brackets for your reference:

    Panel Specification
    Model No FH-D3D460CT
    Panel Size 46" (Industrial Grade A+ panel each bezel 1.7mm)
    Aspect Ratio 16 : 9
    Active Display Area 1018.08(W) x 572.67(H)
    Backlight LED
    Max Resolution Support

    1920x1080 (Each monitor)

    4K 2x2, 6K 3x3 or 8K 4x4

    Large screen support Max 8K

    Color 16.7M
    Brightness(nits) 500nits
    Contrast 3000:1
    Visual Angle (H/V) 178°/178°
    Response Time <6ms
    Life(hrs) >50,000(hrs)
    Video Wall Controller(Built-in each screen)
    VGA input 1
    DVI input 1
    HDMI Input 1
    Composite Video input 2(BNC x 2)
    Y,Pb,Pr/Y,Cb,Cr input 1(BNC X 3)
    Composite Video Output 2(BNC X 2)

    S-video

    USB

    2(BNC X 2)

    1

    Control signal input and loop out RS232(RJ45-8)
    Split Screen Support Picture in Picture(PIP/POP)
    Video System
    Color System PAL/NTSC/SECAM
    HDTV Mode 1080P (Optinal 2K/4K)
    OSD Display(Menu Language) Chinese/English
    Power
    Power supply AC 100V ~ 240V, 50/60Hz
    Maximum Power Consumption <230W
    Standby Power Consumption <3W
    System Supports Windows, Android, and Linux
    Touch screen Infrared touch support 32points (optional)
    Positioning accuracy

    ±2mms

    Output Resolution 8192×8192
    Hardness 7H
    Installation System
    Installation With wall bracket for each unit lcd
    Gross Weight 21kg
    Dimension 1023.98X578.6X101.5mm
    Accessories
    Split LCD Unit Yes
    Bracket Yes(wall bracket for each unit lcd)
    Power cable Yes
    Remote controller Yes
    Video wall controller Yes(Built-in each screen)
    Splicing software Yes

    Besides wall mounted installation mode, we also offer the following complete set cabinet, if you need the cabinet instead of wall mounting installation, you can inquire our salesman about the cost of metal cabinet.

    As for Video Wall System, we offer you 3 solution for reference, you can pick up right solution based on your requirements.

    1) Display one whole content on the LCD video wall units for single input signal by using A video splitter.

    2) Display different contents on the LCD video wall units for multiple input signals by using matrix.

    3) Display different complicated contents on the LCD video wall system for multiple input signals with various signals by using processor.

    1. Q:What is LED/LCD Video Wall System?

    A: LED/LCD Video Wall is integrating multiple signal decoding unit,a liquid crystal drive unit,power supply unit and other parts, can flexible and easily form a large screen display system.which widely used in many fields, like : stadium, exhibition, advertisement playing, and television station, stock market, traffic center and so on.


    2,Q:How can you guarantee the quality of this Products?

    A: Felehoo factory have over 12 years produce experience.All of the products are professional, high quality, artistic design and competitive price. Felehoo people always attach great importance to

    quality controlling from the very beginning to the very end. We focus on every detail We also offer professional technology and after-sale services.


    3.Q:Why is your price some time a little more expensive than others?

    A:Yep, Felehoo use 100% Original A+ Grade TFT Screen and chips ,good material. Ensure that it more stability, and check the products attentively.If you still tell me that just need the cheapest price and don't care any quality. Ok, tell us.But then we are not for the poor quality of responsible.


    4.Q:Everybody say it's good quality, so how to prove, how can I trust one and who can I trust?

    A:We are never hope to do just one business,we are prefer to a long-term cooperation.I know you also don't like change different suppliers,you are looking for the honest supplier. Maybe I can't promise you that is the cheapest price in global, but i can tell you we try our best to offer you the best price to make you always WIN customers and electronic field!So we are very glad to if you are sincerely want to buy. Felehoo factory have the confidence to do your fixed suppliers.

    So let me know your target price and which product you need for so that I can recommend the appropriate type for you, and I will do my utmost to offer you a perfect order. thank your trust!


    5,Q: what is HS code for LED/LCD Video Wall ?

    A: 8528591090 for LED/LCD Video Wall .


    6, Q: what brand of panel are you using for lcd video wall ?

    A: we are using Samsung,LG,Sharp Panel.


    7,Q: How long you can finish the production?

    A: For the sample order, we can finish the production within 7 working days, If we have it in stock, we can send you the sample within 3 days after received your payment.


    8, Q: What is your after-sale service?

    A: One year warranty from the shipping date.We offer 100% guarantee on our product.


    9,Q: Which size of LED/LCD Video Wall do you have?

    A: At present, The screen size range of LED/LCD Video Wall includes: 40"/42"/46/47"/55"/60".

    As for LED/LCD Video Wall solution, we can supply : 1x2,1x3,2x3,3x3,4x2,4x3,4x4,4x5,5x5,

    6x5.6x4,6x3,6x2,7x2,7x3,7x4,7x5,7x6,7x7,8x2,8x3,8x4,8x5,8x6,8x7,8x8,9x2,9x3,9x4,9x5,9x6.


    10,Q : Are you a manufacturer or trading company?

    A: We are a manufacturer who has been specializing in producing LCD display for years.


    11, Q : What is your MOQ?

    A: Any quantity is acceptable for your order. And the price is negotiable for large quantity.


    13, Q : Do you have your own enclosure factory?

    A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope

    to provide you with best screen and shape,so OEM is also welcome.


    14.Q : what payment can you accept ?

    A : T/T, western union ,Paypal for payment terms.

    For Bulk orders : 30% deposit in advance to start the production,balance payment clear before the delivery.

    15, Q : what about the package and transport ?

    A: This question is very important. For sample, i advise that you pick up DHL or Airline as transport mode, for Bulk order, we can send you the goods by sea shipping.

    Felehoo lcd video wall monitors shipping and transportation ways

    As for outer package, if you need sample, we advise that we send you the sample with Flight case. If your demand is not much, we can pack your goods with wooden case. Please notice this point, the cost of flight case and wooden case is not included in price, you need pay extra package cost, this cost based on your quantity, felehoo salesman can check the package cost for you based on your quantity. If you order a large quantity, such as 100pcs or 500pcs, we can pack the goods with carton box. Regarding so large quantity, the goods can be filled in a container. As you known, Container is enough, so you no need pay any extra package cost when you buy a large quantity.

    Felehoo lcd video wall monitors using different professional package and wooden case
